Tour 引导

引导用户按步骤使用界面或完成任务的组件，由 ea-tour 与 ea-tour-step 组成。

引入

原生引入Vite

html

<script type="module">
  import "./node_modules/easy-component-ui/dist/components/ea-tour.js";
</script>

import "easy-component-ui/ea-tour";

基础用法

简单示例：点击按钮开启引导。

Begin Tour

UploadSave

Put you files here.

查看代码

html

<div class="demo">
  <ea-button id="basicTourBtn" variant="primary">Begin Tour</ea-button>
  <hr />
  <ea-button id="basicEl1">Upload</ea-button>
  <ea-button id="basicEl2" variant="primary">Save</ea-button>
  <ea-button id="basicEl3" icon="share-nodes"></ea-button>

  <ea-tour id="basicTour">
    <ea-tour-step target="#basicEl1" heading="Upload File">
      <img
        style="width: 240px"
        src="https://raw.githubusercontent.com/LuminaQAQ/ea-ui-component/refs/heads/dev_3.0/docs/favicon.ico"
        alt="tour.png"
      />
      <div>Put you files here.</div>
    </ea-tour-step>
    <ea-tour-step
      target="#basicEl2"
      heading="Save"
      description="Save your changes"
    ></ea-tour-step>
    <ea-tour-step
      target="#basicEl3"
      heading="Other Actions"
      description="Click to see other"
    ></ea-tour-step>
  </ea-tour>
</div>

<script type="module">
  const basicExample = {
    el: document.querySelector("#basicTour"),
    btn: document.querySelector("#basicTourBtn"),

    init() {
      this.btn.addEventListener("click", () => {
        this.el.visible = true;
      });
    },
  };
  basicExample.init();
</script>

非模态

设置 mask="false" 可让引导非模态显示（不遮罩页面），配合 variant="primary" 可使用主题色样式。

Begin Tour

UploadSave

Put you files here.

查看代码

html

<div class="demo">
  <ea-button id="noMaskTourBtn" variant="primary">Begin Tour</ea-button>
  <hr />
  <ea-button id="noMaskEl1">Upload</ea-button>
  <ea-button id="noMaskEl2" variant="primary">Save</ea-button>
  <ea-button id="noMaskEl3" icon="share-nodes"></ea-button>

  <ea-tour id="noMaskTour" variant="primary" mask="false">
    <ea-tour-step target="#noMaskEl1" heading="Upload File">
      <div>Put you files here.</div>
    </ea-tour-step>
    <ea-tour-step
      target="#noMaskEl2"
      heading="Save"
      description="Save your changes"
    ></ea-tour-step>
    <ea-tour-step
      target="#noMaskEl3"
      heading="Other Actions"
      description="Click to see other"
    ></ea-tour-step>
  </ea-tour>
</div>

<script type="module">
  const noMaskExample = {
    el: document.querySelector("#noMaskTour"),
    btn: document.querySelector("#noMaskTourBtn"),

    init() {
      this.btn.addEventListener("click", () => {
        this.el.visible = true;
      });
    },
  };
  noMaskExample.init();
</script>

位置

通过 placement 属性可设置 ea-tour-step 的出现位置；若不设置 target，可在屏幕中心显示。

Begin Tour

查看代码

html

<div class="demo" style="text-align: center">
  <ea-button id="placementTourBtn" variant="primary">Begin Tour</ea-button>

  <ea-tour id="placementTour">
    <ea-tour-step
      heading="Center"
      description="Displayed in the center of screen."
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Top"
      description="On the top of target."
      placement="top"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Top-Start"
      description="On the top-start of target."
      placement="top-start"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Top-End"
      description="On the top-end of target."
      placement="top-end"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Right"
      description="On the right of target."
      placement="right"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Right-Start"
      description="On the right-start of target."
      placement="right-start"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Right-End"
      description="On the right-end of target."
      placement="right-end"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Bottom"
      description="On the bottom of target."
      placement="bottom"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Bottom-Start"
      description="On the bottom-start of target."
      placement="bottom-start"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Bottom-End"
      description="On the bottom-end of target."
      placement="bottom-end"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Left"
      description="On the Left of target."
      placement="left"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Left-Start"
      description="On the left-start of target."
      placement="left-start"
    ></ea-tour-step>
    <ea-tour-step
      target="#placementTourBtn"
      heading="Left-End"
      description="On the left-end of target."
      placement="left-end"
    ></ea-tour-step>
  </ea-tour>
</div>

<script type="module">
  const placementExample = {
    el: document.querySelector("#placementTour"),
    btn: document.querySelector("#placementTourBtn"),

    init() {
      this.btn.addEventListener("click", () => {
        this.el.visible = true;
      });
    },
  };
  placementExample.init();
</script>

Tour API

Tour Attributes

参数	说明	类型	可选值	默认值
append-to	挂载容器选择器	string	—	body
visible	控制引导是否显示	boolean	—	false
current	当前步骤索引	number	—	0
gap	遮罩与目标元素间距（像素）	number	—	6
mask	是否显示遮罩	boolean	—	true
variant	按钮等样式类型，会传递给子 step	string	`default \| primary`	default
placement	默认步骤弹出位置（当 step 未设置 placement 时生效）	string	top \| top-start \| top-end \| bottom \| bottom-start \| bottom-end \| left \| left-start \| left-end \| right \| right-start \| right-end	bottom

Tour Slots

名称	说明
default	step 子元素插槽

Tour Events

事件名	说明	回调参数(event.detail)
ea-close	引导关闭时触发	`{ current: number }`
ea-tour-change	步骤切换时触发	`{ current: number }`
ea-tour-finish	完成引导时触发	—

Tour CSS Custom Properties

属性名	说明	默认值
--ea-tour-transition	过渡动画时长	var(--transition-normal)
--ea-tour-mask-color	遮罩颜色	rgba(0, 0, 0, 0.5)

TourStep API

TourStep Attributes

参数	说明	类型	可选值	默认值
heading	步骤标题	string	—	""
target	目标元素选择器（缺省则居中显示）	string	—	""
placement	步骤弹出位置	string	top \| top-start \| top-end \| bottom \| bottom-start \| bottom-end \| left \| left-start \| left-end \| right \| right-start \| right-end	bottom
variant	样式类型，会影响按钮类型	string	`default \| primary`	default

TourStep CSS Part

名称	说明
container	step 根元素
header	头部（heading / close）
close-icon	关闭图标
content	内容区域
footer	底部区域
indicator-group	指示器容器
indicator	单个指示器（circle）
switch-group	按钮容器
previous	上一步按钮 part
next	下一步按钮 part
finish	完成按钮 part

TourStep Slots

名称	说明
default	默认插槽，用于步骤内容
header	头部插槽，可自定义标题或关闭按钮
indicator	自定义指示器（覆盖默认圆点）
footer	自定义底部按钮区域

TourStep Methods

方法名	说明	参数
updateIndicators	更新步骤指示器	allSteps: HTMLElement[]

TourStep CSS Custom Properties

属性名	说明	默认值
--ea-tour-step-visible	步骤可见性	none
--ea-tour-step-width	步骤宽度	400px
--ea-tour-step-padding	步骤内边距	var(--spacing-lg)
--ea-tour-step-bg-color	步骤背景颜色	var(--white)
--ea-tour-step-indicator-size	指示器尺寸	6px
--ea-tour-step-indicator-color	指示器颜色	var(--grey-200)
--ea-tour-step-indicator-active-color	激活指示器颜色	var(--blue-500)
--ea-tour-step-close-color	关闭图标颜色	var(--grey-500)
--ea-tour-step-primary-color	主题色	var(--blue-500)
